Der PT-Filter mit Fluidtrichter ist für die platzsparende Aufstellung im Raum konzipiert.
For highly effective, energy-efficient dry separation of fine dust in small spaces
The PT Filter series is especially suitable for the separation of fine, free-flowing dust created by mechanical and thermal processes.
A special feature is the exchange of filter plates on the clean air side for easy maintenance, and reduced height for greater accessibility.
A standard in energy consumption, clean air recirculation, and low profile
Low filter resistance and efficient fans reduce energy consumption, and high-quality filter elements enable clean air recirculation into the workplace.
Further information:
Brochure "PT-Filter-units - Separation of fine dust particles"
Dimensions and technical information
PT filter elements are modular to meet different requirements, such as dust characteristics or the volume of exhausted air. Their low profile also enables easy installation in difficult access areas.
| Type | PT-114 | PT-121 | PT-228 | PT-242 |
|---|---|---|---|---|
| Max. air flow [m³/h] | 16000 | 24000 | 32000 | 48000 |
| Power [kW] | 11,0 – 18,5 | 18,5 – 30,0 | 22,0 – 37,0 | 30,0 – 45,0 |
| Max. number of filter elements [pc.] | 14 | 21 | 28 | 42 |
| Filter surface [m²] | 129,7 | 194,6 | 259,4 | 389,3 |
| Floor space (L/W/H) [mm] | 2444 x 1680 x 5720 | 2444 x 2450 x 6320 | 2444 x 1680 x 6870 | 2444 x 2450 x 7470 |
